SQC/PC-2200/2500/2800-4D Casting Type Guide Pillars Block Cutting Machine

  • Features
  • Details
  • Case
  • Video

1. Whole casting crossbeam structure, uses inverter to control left-right feeding and adjusts the speed according to stone materials, walking is more flexible and with good cutting flatness.

2. The forward-backward walking uses high precision screw nut driving, combined with ultra-high precision rotary encoder to slice, with high slicing precision.

3. Use double hydraulic cylinders lifting system, combined with chrome-plated guide pillars lifting, more stable and durable.

4. The shaft of spindle box adopts high quality alloy steel and V belt’s flexible coupling drive, with low bearing temperature and long service life.

5. Independently developed control system,equipped with Siemens electronic components,the whole machine with good electronic control performance and high cutting efficiency.


名称 Appellation unit SQC/PC-2200/2500/2800-4D
横梁 Crossbeam mm 7500/8000/8500
导柱直径 Guide pillar diameter mm Φ140 (Can choose Φ180)
锯片直径 Diameter of saw blade mm Φ2200 Φ2500 Φ2800
最大升降行程 Max.lifting stroke mm 1150 1350 1350
左右有效行程 Left-right effective stroke mm 7500边梁 - 行程3600
8000边梁 - 行程4100
8500边梁 - 行程4600
7500边梁 - 行程3300
8000边梁 - 行程3800
8500边梁 - 行程4300
7500边梁 - 行程3000
8000边梁 - 行程3500
8500边梁 - 行程4000
边梁 Sidebeam mm 3700-7500
前后行程 Forward-backward stroke mm 3700边梁 - 行程2200      4500边梁 - 行程3000
5500边梁 - 行程4000      7500边梁 - 行程6000
耗水量 Water consumption m³/h 15
主电机功率 Power of main motor kw 37 45 45
总功率 Total power kw 48 56 56
外形尺寸(长×高)
(从基础至最高点)
Dimension(L×H) mm 8000/8500/9000×3700
总重量 Weight kg 14000-16000

Kind reminder: If you would like to know more details, specifications, standards, prices, and solutions, please contact us.
